DALI OPTICON VOKAL MK2 Satin Black Centrālā akustiskā sistēma (cena par gab.)

DALI OPTICON VOKAL MK2 Satin Black Centrālā akustiskā sistēmaDALI OPTICON VOKAL MK2 Satin Black Centrālā akustiskā sistēmaDALI OPTICON VOKAL MK2 Satin Black Centrālā akustiskā sistēmaDALI OPTICON VOKAL MK2 Satin Black Centrālā akustiskā sistēmaDALI OPTICON VOKAL MK2 Satin Black Centrālā akustiskā sistēmaDALI OPTICON VOKAL MK2 Satin Black Centrālā akustiskā sistēma
€ 579.99 Bez atlaides € 599.00
  • Sazināties
  • Vēlos pasūtīt
sadalīt 6 daļās = € 96.67
Preces kods: OPTICON VOKAL MK2 SATIN BLACK

AVEX salons tagad Brīvības gatvē 226 K-4, Rīgā

Vairāk kā 500m2 plašas telpas, kuras piepildītas ar lieliskiem audio produktiem dažādām gaumēm un finansiālajām iespējām!

Privāta BEZMAKSAS STĀVVIETA KLIENTIEM tieši pie jaunā salona!

Ja pie šī produkta redzi atzīmi "IR VEIKALĀ" tad dotais produkts ir mūsu veikalā

1. Vari droši veikt pirkumu tiešsaistē izvēloties piegādes veidu. Ja pirkums tiešsaistē tiks veiksmīgi veikts darba dienā līdz plkst. 12.00, tad tajā pašā dienā tas tiks atdots uz piegādi un saņemsi to norādītajā adresē nākamajā vai aiznākamajā dienā

2. Vari doties uz mūsu veikalu, kur to varēsi iegādāties uzreiz.

Ja tomēr izvēlētais produkts dotajā brīdī nav mūsu veikalā, sazinies ar mums, veicot tā pieprasījumu un mēs GARANTĒJAM ka piegādāsim to maksimāli īsākajā laikā.

P.S. Rēķins tiks nosūtīts tikai tajā gadījumā, kad mēs par 100% būsim pārliecināti, kad šis produkts ir pieejams ražotāja noliktavā un tā piegāde būs bez aizķeršanās!

Vēlies tomēr uzdot mums kādu interesējošu jautājumu? Zvani 22003030


Īss apraksts (angļu val.)
Izvērsts apraksts (angļu val.)
Specifikācija (angļu val.)

DALI OPTICON VOKAL MK2

The OPTICON VOKAL MK2 is specifically voiced to play the centre channel role, but at the same time it displays all the characteristic qualities that enable it to dovetail perfectly in a full OPTICON MK2 audio visual system.

The OPTICON VOKAL MK2 is specifically voiced to play the centre channel role, but at the same time it displays all the characteristic qualities that enable it to dovetail perfectly in a full OPTICON MK2 audio visual system.

The centre channel offers a level of performance unavailable from any other OPTICON model. It combines immense low frequency bandwidth, volume potential and dynamic accuracy with the extraordinary detail and clarity that arises from the use of a dedicated midrange driver. High frequencies from the hybrid tweeter are explicitly detailed and informative yet simultaneously smooth and endlessly listenable.

The enclosure dimensions and proportions are specifically configured to enable its installation in audio-visual furniture units, and its front facing reflex ports mean that even fully enclosed mounting is feasible.

This makes it perfect for placement up against a wall underneath the TV or projector screen or even hidden away in a HiFi furniture when not in use, which it also has been specifically designed for - a nice feature for aesthetically minded home theatre owners.

The OPTICON VOKAL MK2 is the perfect partner for any speaker in the OPTICON MK2 series, with the same level of detail and coherence – but also powerful enough to be used even with the OPTICON 8 MK2.

The manufacture of the entire series remains fully Danish - as with the MK1 series. Built at our factory in Denmark; from components produced in-house or sourced from the best specialist manufacturers locally and further afield.

SMC

The OPTICON VOKAL MK2 driver magnet system consists of a large ferrite ring magnet surrounding a pole piece manufactured entirely of the unique DALI SMC material. The pole piece and the ferrite magnet are secured between soft iron front and back plates to create the appropriate magnetic field for the voice-coil.

DALI SMC (Soft Magnetic Compound) is a coated magnet granular material that can be formed to almost any desired shape and has many advantages used in driver magnet systems. SMC’s unusual combination of very high magnetic permeability and very low electrical conductivity is exactly what is required for driver magnet systems and results in a significant reduction of electro-acoustic distortion.

SMC works primarily by minimising eddy currents in the magnet system pole piece, which reduces distortion. SMC also improves flux linearity within the magnet system - reducing magnetic hysteresis. All of these SMC benefits together produce a significant subjective reduction of low-level detail masking and colouration.

HYBRID TWEETER

SOFT DOME
The new unique light-weight 29 mm soft dome tweeter is derived from CALLISTO C and offers significant advances over the tweeters used in the MK1 series. The relatively small increase in diameter over the previous 28 mm tweeter results in a significant increase in dome radiating area. This means lower distortion, higher power handling, and an ability to operate at lower frequencies.

The use of the same 29 mm soft dome tweeter across all six OPTICON MK2 models results in consistency of tonal character and provides consistency of dispersion characteristics. The MK2 soft dome tweeter enables crossover frequencies as low as 2kHz to be safely employed with no risk of distortion or power handling limitations.

HYBRID TWEETER
The OPTICON VOKAL MK2 employs a new hybrid tweeter design that marries the 29 mm soft dome tweeter with a custom 17 x 45 mm ribbon. Both mounted on a cast aluminium faceplate, which incorporates dispersion control detailing.

The ribbon element begins to contribute from 10kHz upwards; just as the response of the soft dome element is beginning slowly to fall away and become more directional. The ribbon element both extends the system frequency response towards 30kHz and contributes to keep high frequency horizontal dispersion wider than would otherwise be the case.

The new hybrid tweeter offers the best of both worlds – the clarity, speed and dynamics of a dome tweeter, with the very high frequency detail and smooth finesse of a ribbon tweeter.

The placement of the hybrid tweeter drivers between the two widely spaced bass drivers is done firstly in order to position the high frequency drivers near typical seated ear height. Secondly to take advantage of the smoother low frequency room response that results from spaced bass drivers.

WOOFER

The 6½” wood fibre driver handles the low frequencies and the midrange - both build around DALI's patented SMC magnet motor system.

Every component of the driver is carefully designed for its positive contribution towards ideal performance. The diaphragms are made from a mix of paper and wood fibre that ensures minimal break-up resonance and gives the diaphragms their distinctive DALI trademark colour. They are terminated by rubber surrounds chosen for their soft and very flexible mechanical properties that enable free movement with minimal low frequency damping.

The driver chassis for each driver is manufactured in die-cast aluminium that provides extremely high rigidity and low resonance along with minimal extraneous influence on the internal magnet system. The mechanical design of the chassis is specifically engineered to provide minimal impedance to airflow while at the same time enabling extremely tight mechanical bonding with the speaker enclosures.

The drivers were designed with a consistent focus on the DALI audio principles of low-loss, low distortion and low colouration. The ideal driver plays only what the amplifier requires, with nothing added and nothing subtracted, and at DALI we strive to design and manufacture drivers that approach the ideal as closely as possible.

CABINET

The enclosure of the OPTICON VOKAL MK2 is designed to optimise rigidity and minimise panel resonance. The 25mm thick front baffle provides massively rigid foundations for the drivers.

The manufacturing of the OPTICON MK2 series has been retained firmly at the DALI factory in Denmark. Our in-house woodworking facility handles everything from cutting and routing the MDF panels to the driver and crossover installation. The final test and quality approval on each and every speaker is also handled on our own assembly lines.

The reflex ports employed in the centre speaker is not Dual Flare design, however the ports are no less carefully considered. The OPTICON VOKAL MK2 employs twin, forward facing letterbox style reflex ports configured to enable the system to be enclosed in furniture units. Not only does its enclosure format not provide enough space for Dual Flare, port flaring is less critical on a system designed primarily for voice reproduction.

Frequency Range (+/-3 dB) [Hz] 47 - 30,000
Sensitivity (2,83 V/1 m) [dB] 88
Nominal Impedance [ohms] 4
Maximum SPL [dB] 109
Recommended Amplifier Power [W] 30 - 150
Crossover Frequency [Hz] 2,400 / 14,000
Crossover Principle 2 + ½-way
Hybrid tweeter module, Super high freq. driver, Quantity 1 x 17 x 45 mm
Hybrid tweeter module, Super high freq. driver, Diaphragm type Ribbon
Hybrid tweeter module, High frequency driver, Quantity 1 x 29 mm
Hybrid tweeter module, High frequency driver Diaphragm type Soft Textile Dome
Midrange driver, Quantity 1 x 6 1/2"
Midrange driver, Diaphragm type Wood Fibre Cone
Enclosure type Bass Reflex
Bass Reflex Tuning Frequency [Hz] 44
Connection Input Single Wire
Magnetic Shielding No
Recommended Placement Shelf or stand
Centre / Soundbar
Recommended Distance From Wall [cm] 0 - 30
Dimensions With Base (HxWxD) [mm] 201 x 435 x 312
Accessories Included Manual
Rubber Feet
Weight [kg] 9.2
